    BDS 4 in. Suspension Lift Kit

    2 sold in last 8 hours
    BDS Suspension
    BDS1963H
    Many in stock
    Suspension Lift Kit
    $2,312.70
    BDS 4 in. Suspension Lift Kit | BDS1963H | 2019 - 2020 Ford F150 Raptor Click...
    Size Guide
    $2,312.70
    customers are viewing this product
    BDS Suspension 1in. Rear Lift Blocks | Dual Pin for use on Ford F150
    BDS Suspension 1in. Rear Lift Blocks | Dual Pin for use on Ford F150
    $103.95
    Zone Offroad 3 Inch Lift Kit With Nitro Shocks 2018 - 2026 Jeep Wrangler JL
    Zone Offroad 3 Inch Lift Kit With Nitro Shocks 2018 - 2026 Jeep Wrangler JL
    $500.75
    BDS 4 in. Suspension Lift Kit
    Description

    BDS 4 in. Suspension Lift Kit | BDS1963H | 2019 - 2020 Ford F150 Raptor

    Click HERE to download installation guide

    OVERVIEW

    Take full advantage of the Raptor's FOX Live Valve shocks when you install a 4-inch suspension lift kit by BDS Suspension on your 2019-2020 Ford F150 Raptor. After months of engineering, BDS determined that the 4" lift height allows for the best use of the factory equipped FOX Shocks and maintain full range of suspension travel allotted by the factory suspension components. This kit includes everything necessary to set your truck up right with clearance for up to 37" tires.

    This kit takes advantage of BDS's tried and true high-clearance design for improved ground clearance, strength, and offroad protection while correcting suspension and steering geometry for great on-road handling characteristics. Up front the kit utilizes high-arched 1/4-inch thick steel crossmembers, lower strut extension, multipiece differential relocation brackets and skidplate designed for offroad protection. Steering geometry is corrected at the new taller ride height with a pair of massive CNC-machined ductile iron steering knuckles. These combined with the provided sway bar relocation brackets, brake line brackets, alignment cam bolts, supplied hardware and more provide a comprehensive front suspension lift ready for use and abuse.

    In the rear BDS utilizes high strength lift blocks and longer u-bolts to lift and level the stance along with rear shock relocation brackets to maintain the FOX internal bypass rear shocks.

    High Clearance Crossmembers

    BDS maximizes ground clearance with their heavy duty 1/4-inch thick laser cut perfect fit crossmembers. Paired with a front skid plate system that bolts together to create a rigid subframe while adding extra protection.

    Heavy Duty Steering Knuckles

    BDS corrects steering geometry at the new taller ride height using a pair of high-strength, CNC machined ductile cast iron steering knuckle design to work with replacement tie rod ends to maintain steering angles for proper function and ESC compatibility.

    Features & Benefits

    • High clearance crossmembers improve strength and offroad capability
    • Heavy duty steering knuckles to correct steering geometry and maintain ESC system compatibility
    • Top mounted strut spacers to provide lift and install easily
    • Differential skid plate for improved offroad protection
    • Rear lift blocks and u-bolts to lift and level the stance
    • Shock relocation brackets to maintain factory FOX Shocks

    Recommended Tires & Wheels

    (Trimming may be required)

    • 37 x 12.5 with 18 x 9 and 5 in. Backspace
    • 37 x 12.5 with 20 x 9 and 5 in. Backspace

    Rear Lift Option

    5 Inch Block Kit

    • Level to tail high appearance

    4 Inch Block Kit

    • Tail low to level stance

    Important Notes

    1. Required frame bracket modification and welding.
    2. Stock wheels cannot be reinstalled with a lift.
    3. Check for proper tie rod end clearance if using 37x12.50 tires on 18x9 (5" BS) wheels
